Deep Well Injector Pumps
Deep Well Injector Pump 0.75HP
P-Code 101
Coupled self-priming deep well injector pump. The venturi injector allows lifting water from depths up to 40 ft. Cast iron body with brass/steel impeller.
Ideal Use Cases
- ✓Deep well water lifting
- ✓Domestic supply from wells
- ✓Agricultural wells
Technical Specifications
- Model Code
- P-Code 101
- Size
- 1.5" × 1"
- Motor Power
- 0.75 HP
- Voltage
- 220V
- Current
- 3A
- Max Suction
- 40 ft
- Max Head
- 131 ft
- Max Discharge
- 40 L/min
